Datasheet Outline Drawing
The Clinometer Pak 420 is the packaged version of our Tulip 4-20 mA clinometer. Its rugged aluminum enclosure provides mechanical and environmental protection for indoor or outdoor use. This uniaxial instrument is current loop-powered, so measurements can be made over long cables using an economical 2-wire pair. It also measures temperature using a built-in thermistor. Use it to monitor the angular position of conveyers, booms, ramps, and machinery; perform antenna tilt error corrections; and track the pitch and roll of ships, buoys, ROVs, and towfish.
Specifications
| High-Gain | Standard | Wide-Angle | |
| Angular Range (°) | ±10 | ±25 | ±50 |
| Resolution (°)1 | 0.005 | 0.01 | 0.02 |
| Repeatability (°) | 0.02 | 0.02 | 0.02 |
| Scale Factor (°/mA)2 | 1.25 | 3.125 | 6.25 |
| Non-linearity (%)3 | 1 | 2.5 | 7 |
| Output Voltage (V) | 4-20mA, 2-wire current loop | ||
| Channels | Tilt, Thermistor | ||
| Kz Coefficient (°/C, typical) | 10-20 arcsec | ||
| Ks Coefficient (%/C, typical) | 0.03 | ||
| Time Constant (seconds) | 0.15 | ||
| Natural Frequency (Hz) | 10 | ||
| Power | (0.02 Ampere x R + 10 VDC) < Vs < 29 VDC | ||
| Environmental | -40 to +85°C operation and storage. IP65 | ||
| Materials | Die-cast aluminum, painted | ||
| Cable | 3m (10ft), 5-conductor + one overall shield, PVC jacket, tinned ends | ||
| Weight | 17.6 oz |
| Dimensions | 4.72 × 3.15 × 2.36 in |
